Pipe press sleeve
Code
CT000016Version
3
Group
Connection Type Classes (MG000001)Release
Drawing
Features
01 | Di | Inner diameter (mm) EF000065 - Numeric | |
02 | DN | Nominal diameter EF023191 - Alphanumeric | |
03 | Do | Outer diameter (mm) EF000015 - Numeric | |
04 | Dr | Rim diameter (mm) EF010037 - Numeric | |
05 | j | Distance to edge (mm) EF010519 - Numeric | |
06 | L | Length (mm) EF001438 - Numeric | |
07 | P | Sleeve length (mm) EF010520 - Numeric | |
08 | t | Rim thickness (mm) EF010038 - Numeric | |
09 | Z | Working length (mm) EF006318 - Numeric |
Synonyms
Pipe press sleeve
Press sleeve
