Multimeter
Code
EC000069Version
Group
Electrical testing and measuring instruments (EG020093)Release
DYNAMIC, ETIM-10.0
Features
01 | Indication EF000350 - Alphanumeric | |
02 | Scaling bar graph linear EF016453 - Logical | |
03 | Scaling bar graph logarithmic EF016454 - Logical | |
04 | Multiple display EF005005 - Logical | |
05 | With display backlight EF012740 - Logical | |
06 | Measuring range selection EF000413 - Alphanumeric | |
07 | Max. voltage measuring range AC (V) EF004989 - Numeric | |
08 | Lowest resolution, AC voltage EF004840 - Alphanumeric | |
09 | Max. voltage measuring range DC (V) EF004990 - Numeric | |
10 | Lowest resolution, DC voltage EF004838 - Alphanumeric | |
11 | Max. voltage measuring range AC/DC (V) EF017749 - Numeric | |
12 | Lowest resolution, AC/DC voltage EF017750 - Alphanumeric | |
13 | Max. current measuring range, AC (A) EF004991 - Numeric | |
14 | Lowest resolution, AC current EF004841 - Alphanumeric | |
15 | Max. current measuring range, DC (A) EF004992 - Numeric | |
16 | Lowest resolution, DC current EF004839 - Alphanumeric | |
17 | Max. current measuring range, AC/DC (A) EF017751 - Numeric | |
18 | Lowest resolution, AC/DC current EF017752 - Alphanumeric | |
19 | Max. current measuring range with clip factor (A) EF017111 - Numeric | |
20 | Clip factors for current sensor EF017746 - Alphanumeric | |
21 | Clip factors for current transformer EF017747 - Alphanumeric | |
22 | Max. resistance measuring range (MOhm) EF004997 - Numeric | |
23 | Milliohm measurement with 4 wire technique (Kelvin connection) EF009853 - Logical | |
24 | Lowest resolution, resistance EF004842 - Alphanumeric | |
25 | Temperature measurement RTD EF009854 - Logical | |
26 | Temperature measurement EF006229 - Logical | |
27 | Temperature measurement TC EF009855 - Logical | |
28 | Max. temperature measuring range (°C) EF009175 - Numeric | |
29 | Lowest resolution temperature EF009176 - Alphanumeric | |
30 | Capacitance measurement EF000597 - Logical | |
31 | Max. capacitance measuring range (µF) EF009177 - Numeric | |
32 | Lowest resolution, capacitance EF009178 - Alphanumeric | |
33 | Frequency measurement EF000599 - Logical | |
34 | Max. frequency measuring range (kHz) EF009179 - Numeric | |
35 | Lowest resolution, frequency EF009180 - Alphanumeric | |
36 | Resistance test/diode test EF004615 - Logical | |
37 | Isolation resistance measuring range (MOhm) EF000590 - Range | |
38 | Measurement principle EF001006 - Alphanumeric | |
39 | Relative measurement accuracy (%) EF004044 - Numeric | |
40 | Nominal test voltage 10 V EF009856 - Logical | |
41 | Nominal test voltage 50 V EF009857 - Logical | |
42 | Nominal test voltage 100 V EF005117 - Logical | |
43 | Nominal test voltage 250 V EF005119 - Logical | |
44 | Nominal test voltage 500 V EF005121 - Logical | |
45 | Nominal test voltage 1000 V EF005118 - Logical | |
46 | Cable length measurement EF009858 - Logical | |
47 | Cable symmetry testing for two wire connections a-b-E EF009859 - Logical | |
48 | Power and energy measurement EF009860 - Logical | |
49 | Harmonics analysis/power quality EF009861 - Logical | |
50 | With decibel measurement (dB) EF000600 - Logical | |
51 | Relative value measurement EF005205 - Logical | |
52 | Inductance measurement EF004789 - Logical | |
53 | With conductivity measurement EF004899 - Logical | |
54 | Continuity test EF000588 - Logical | |
55 | Data hold EF001849 - Logical | |
56 | Max. value storage EF005002 - Logical | |
57 | Min. value storage EF005029 - Logical | |
58 | Peak value memory EF005300 - Logical | |
59 | High voltage test for motor windings EF017110 - Logical | |
60 | True RMS measurement EF000420 - Logical | |
61 | Duty cycle measurements EF005336 - Logical | |
62 | Rotational speed measuring EF009862 - Logical | |
63 | Measured value memory EF000307 - Logical | |
64 | Interface EF000594 - Logical | |
65 | Bluetooth interface EF004540 - Logical | |
66 | IR interface EF003861 - Logical | |
67 | Automatic circuit breaker EF009863 - Logical | |
68 | Measuring circuit category EF005014 - Alphanumeric | |
69 | Max. voltage measuring circuit category (V) EF009864 - Numeric | |
70 | Current supply EF000145 - Alphanumeric | |
71 | Explosion-tested version EF004191 - Logical | |
72 | Degree of protection (IP) EF005474 - Alphanumeric | |
73 | Calibration according to ISO/IEC 17025 EF008383 - Logical | |
74 | Calibration certificate according to DAkkS EFDE0104 - Logical | |
75 | COFRAC certified EFFR0010 - Logical |
Synonyms
Ampere meter
Analog multimeter
Digital multimeter
Frequency meter
Multi meter
Multimeter
Multitester
Test device
Universal meter
Voltmeter
VOM
VOM meter
