Busbar trunk unit

Code

MC000188

Electrical - Power distribution and protection (MG000017)

Drawing

Features

01		Model EF000010 - Alphanumeric
02		Number of tap-off units EF007583 - Numeric
03	H1	Height 1 (mm) EF010005 - Numeric
04	Hc	Height connector (mm) EF010986 - Numeric
05	Hi	Inner height (mm) EF010059 - Numeric
06	Ho	Height (mm) EF000040 - Numeric
07	IL	Insert length (mm) EF020279 - Numeric
08	L	Length (mm) EF001438 - Numeric
09	Lr	Length busbar trunk (mm) EF007905 - Numeric
10	L1	Length 1 (mm) EF021554 - Numeric
11	L2	Length 2 (mm) EF021555 - Numeric
12	L3	Length 3 (mm) EF021750 - Numeric
13	L4	Length 4 (mm) EF010951 - Numeric
14	L5	Length 5 (mm) EF010961 - Numeric
15	L6	Length 6 (mm) EF010962 - Numeric
16	L7	Length 7 (mm) EF010964 - Numeric
17	L8	Length 8 (mm) EF010965 - Numeric
18	L9	Length 9 (mm) EF011183 - Numeric
19	L10	Length 10 (mm) EF010970 - Numeric
20	L11	Length 11 (mm) EF011184 - Numeric
21	L12	Length 12 (mm) EF010971 - Numeric
22	Lc	Length connector (mm) EF010980 - Numeric
23	W1	Width 1 (mm) EF023087 - Numeric
24	Wi	Inner width (mm) EF010004 - Numeric
25	Wo	Width (mm) EF000008 - Numeric

Related productclasses

Synonyms

Busbar trunk unit
