Punched plate grille

Code

MC000402

Ventilation - Air terminals (inlet/extract) (MG000004)

Drawing

Features

01		Grille front EF022988 - Alphanumeric
02	Do	Front diameter (mm) EF022765 - Numeric
03	Wf	Front width (mm) EF022764 - Numeric
04	Hf	Front height (mm) EF022768 - Numeric
05	Df	Front thickness (mm) EF016398 - Numeric
06	s	Material thickness (mm) EF000386 - Numeric
07		Shape of passage EF021220 - Alphanumeric

Related productclasses

Synonyms

Punched plate grille
