Trip block for power circuit-breaker
Code
EC000617Version
Group
Low-voltage control systems (EG020090)Release
DYNAMIC, ETIM-10.0
01 | Type of motor protection EF008234 - Alphanumeric | |
02 | Number of poles EF001391 - Numeric | |
03 | Rated permanent current Iu (A) EF001389 - Numeric | |
04 | Rated switch current (A) EF006706 - Numeric | |
05 | Overload release current setting (A) EF002336 - Range | |
06 | Short-circuit release function EF001413 - Alphanumeric | |
07 | Current setting delayed short-circuit release (A) EF018171 - Range | |
08 | Current setting undelayed short-circuit release (A) EF018170 - Range | |
09 | With ground fault protection function EF005601 - Logical | |
10 | External power supply required EF003292 - Logical | |
11 | Voltage type (supply voltage) EF002991 - Alphanumeric | |
12 | Supply voltage AC 50 Hz (V) EF007532 - Range | |
13 | Supply voltage AC 60 Hz (V) EF007533 - Range | |
14 | Supply voltage DC (V) EF007534 - Range | |
15 | Number of auxiliary contacts as normally closed contact EF001377 - Numeric | |
16 | Number of auxiliary contacts as normally open contact EF001376 - Numeric | |
17 | Number of auxiliary contacts as change-over contact EF003531 - Numeric | |
18 | Voltage type (operating voltage) EF005294 - Alphanumeric | |
19 | Operating voltage AC 50 Hz (V) EF008206 - Range | |
20 | Operating voltage AC 60 Hz (V) EF008207 - Range | |
21 | Operating voltage DC (V) EF008208 - Range | |
22 | Width (mm) EF000008 - Numeric | |
23 | Height (mm) EF000040 - Numeric | |
24 | Depth (mm) EF000049 - Numeric |
Monitoring unit
Over current protection
Overcurrent protection
Shunt release (for power circuit breaker)
Thermal protection
Thermal release
Trip block for power circuit-breaker
Tripping bloc for power circuit-breaker
