Base conduit end cap
Code
MC000009Version
3
Group
Piping - Pipe fittings, flanges and adaptors (MG000023)Release
Drawing
Features
Features port 1
01 | Connection 1 EF000321 - Alphanumeric | ||
02 | C1 | Height screw gland (mm) EF010040 - Numeric | |
03 | DN1 | Nominal diameter connection 1 EF023193 - Alphanumeric | |
04 | Do1 | Outer pipe diameter connection 1 (mm) EF020122 - Numeric | |
05 | Dr1 | Rim diameter (mm) EF010037 - Numeric | |
06 | g1 | Height screw gland edge (mm) EF010516 - Numeric | |
07 | j1 | Distance to edge (mm) EF010519 - Numeric | |
08 | L1 | Length of connection 1 (mm) EF020151 - Numeric | |
09 | SLW1 | Wrench width union nut (mm) EF022259 - Numeric | |
10 | t1 | Rim thickness (mm) EF010038 - Numeric |
Related productclasses
Synonyms
Base conduit end cap
Fitting with 1 connection
