Code
MC000262Version
Group
Ventilation - Air conditioners and heat pumps (MG000005)Release
Drawing
Features
01 | Model (indoor unit) EF024942 - Alphanumeric | ||
02 | BP | Outlet pattern EF020001 - Alphanumeric | |
06 | CA4 | Position thermostat cable (mm) EF011429 - Coordinate | |
07 | CA5 | Position electrical connection (mm) EF010979 - Coordinate | |
08 | CA6 | Position control cable (mm) EF011430 - Coordinate | |
09 | D | Depth indoor unit (mm) EF000866 - Numeric | |
10 | D1 | Depth 1 (mm) EF010952 - Numeric | |
17 | H | Height indoor unit (mm) EF000865 - Numeric | |
18 | H1 | Edge height (mm) EF021511 - Numeric | |
34 | W | Width indoor unit (mm) EF000864 - Numeric | |
35 | W1 | Width 1 (mm) EF023087 - Numeric |
Features port 1
03 | CA1 | Position connection (mm) EF011006 - Coordinate | |
11 | DN1 | Nominal diameter fluid pipe EF024967 - Alphanumeric | |
14 | Do1 | Outer pipe diameter of fluid pipe (mm) EF024968 - Numeric | |
19 | L1 | Connection length (mm) EF022519 - Numeric | |
22 | P1 | Sleeve length (mm) EF010520 - Numeric | |
25 | Q1 | Length gusset/thread (mm) EF010521 - Numeric | |
28 | RV1 | Directional vector connection EF011005 - Coordinate | |
31 | s1 | Wall thickness connection (mm) EF010546 - Numeric | |
36 | Connection EF000443 - Alphanumeric |
Features port 2
04 | CA2 | Position connection (mm) EF011006 - Coordinate | |
12 | DN2 | Nominal diameter suction pipe EF020136 - Alphanumeric | |
15 | Do2 | Outer pipe diameter suction pipe (mm) EF020139 - Numeric | |
20 | L2 | Connection length (mm) EF022519 - Numeric | |
23 | P2 | Sleeve length (mm) EF010520 - Numeric | |
26 | Q2 | Length gusset/thread (mm) EF010521 - Numeric | |
29 | RV2 | Directional vector connection EF011005 - Coordinate | |
32 | s2 | Wall thickness connection (mm) EF010546 - Numeric | |
37 | Connection EF000443 - Alphanumeric |
Features port 3
05 | CA3 | Position connection (mm) EF011006 - Coordinate | |
13 | DN3 | Nominal diameter EF023191 - Alphanumeric | |
16 | Do3 | Outer pipe diameter condensate drain (mm) EF024969 - Numeric | |
21 | L3 | Connection length (mm) EF022519 - Numeric | |
24 | P3 | Sleeve length (mm) EF010520 - Numeric | |
27 | Q3 | Length gusset/thread (mm) EF010521 - Numeric | |
30 | RV3 | Directional vector connection EF011005 - Coordinate | |
33 | s3 | Wall thickness connection (mm) EF010546 - Numeric | |
38 | Connection EF000443 - Alphanumeric |
Related productclasses
Synonyms
Air-conditioning split system - inside unit (cassette)
Cassette fan coil air conditioner
Cassette fan coil unit (ceiling-mounted)
Ceiling-mounted AC cassette
Fan coil unit
