Radiator stop valve (straight with bend without button)

Code

MC000335

Hydronic - Valves and control components (MG000042)

Drawing

Features

01		Model EF000010 - Alphanumeric
02		Shape EF000051 - Alphanumeric
03		Operation EF002147 - Alphanumeric
10	Le2	Distance to operating element (mm) EF010523 - Numeric
11	Le3	Distance to centre connection (mm) EF010708 - Numeric

Features port 1

04	C1	Height screw gland (mm) EF010040 - Numeric
06	DN1	Size of radiator connection EF021250 - Alphanumeric
08	Do1	Outer pipe diameter connection (mm) EF020208 - Numeric
12	Q1	Length gusset/thread (mm) EF010521 - Numeric
14	s1	Wall thickness connection (mm) EF010546 - Numeric
16	SLW1	Wrench width (mm) EF000177 - Numeric
18	Z1	Working length connection 1 (mm) EF020153 - Numeric
20		Port connection code EF010809 - Numeric
23		Connection EF000443 - Alphanumeric

Features port 2

05	C2	Height screw gland (mm) EF010040 - Numeric
07	DN2	Size of pipe connection EF021187 - Alphanumeric
09	Do2	Outer pipe diameter connection (mm) EF020208 - Numeric
13	Q2	Length gusset/thread (mm) EF010521 - Numeric
15	s2	Wall thickness connection (mm) EF010546 - Numeric
17	SLW2	Wrench width (mm) EF000177 - Numeric
19	Z2	Working length connection 2 (mm) EF020154 - Numeric
21		Port connection code EF010809 - Numeric
24		Connection EF000443 - Alphanumeric

Features port 3

Port connection code

EF010809 - Numeric

Related productclasses

Synonyms

Radiator stop valve (straight with bend without button)
