Solar collector
MC000342 / v3

Code

MC000342

Version

3

Group

Renewable - Solar (MG000040)

Release

nl 2BA se RSK be InstallData fi Sahkonumerot
1 / 2
Drawing
Dimensional drawing
Features

01

H

Height (mm)

EF000040 - Numeric

02

L

Length (mm)

EF001438 - Numeric

03

T

Thickness (mm)

EF000125 - Numeric

04

W

Width (mm)

EF000008 - Numeric

05

W1

Width 1 (mm)

EF023087 - Numeric
Features port 1
CT000001/0
CT000008/0
CT000016/0
CT000017/0

06

CA

Position connection (mm)

EF011006 - Coordinate

10

DV

Directional vector

EF016511 - Coordinate
Features port 2
CT000001/0
CT000008/0
CT000016/0
CT000017/0

07

CA

Position connection (mm)

EF011006 - Coordinate

11

DV

Directional vector

EF016511 - Coordinate
Features port 3
CT000001/0
CT000008/0
CT000016/0
CT000017/0

08

CA

Position connection (mm)

EF011006 - Coordinate

12

DV

Directional vector

EF016511 - Coordinate
Features port 4
CT000001/0
CT000008/0
CT000016/0
CT000017/0

09

CA

Position connection (mm)

EF011006 - Coordinate

13

DV

Directional vector

EF016511 - Coordinate
Related productclasses

EC010350/0

Synonyms

Solar collector
