Dome skylight
Code
MC000436Version
2
Group
Architectural - Doors, windows and hatches (MG000014)Release
Drawing
Features
01 | Shape EF000051 - Alphanumeric | ||
02 | D | Diameter (mm) EF000551 - Numeric | |
03 | Dc | Diameter in the clear (mm) EF025338 - Numeric | |
04 | Do | Diameter roof opening (mm) EF010530 - Numeric | |
05 | Dp | Diameter roof flashing (mm) EF021537 - Numeric | |
06 | H | Height (mm) EF000040 - Numeric | |
07 | H2 | Edge height (mm) EF021511 - Numeric | |
08 | Hu | Height roof upstand (mm) EF010508 - Numeric | |
09 | L | Length (mm) EF001438 - Numeric | |
10 | Lc | Length in the clear (mm) EF025311 - Numeric | |
11 | Lo | Length roof opening (mm) EF010507 - Numeric | |
12 | Lp | Length roof flashing (mm) EF021494 - Numeric | |
13 | W | Width (mm) EF000008 - Numeric | |
14 | Wc | Width in the clear (mm) EF025312 - Numeric | |
15 | Wo | Width roof opening (mm) EF010506 - Numeric | |
16 | Wp | Width roof flashing (mm) EF021493 - Numeric |
Related productclasses
Synonyms
Dome rooflight
Dome skylight
Skylight dome
