Wall transit for cables and tubes

Code

EC000220

Electrical installation, isolation and connection material (EG000047)

DYNAMIC, ETIM-10.0

Features

	01	Model EF000010 - Alphanumeric
	02	Cable diameter (mm) EF002356 - Range
	03	Tube diameter (mm) EF005215 - Range
	04	Length (mm) EF001438 - Numeric
	05	Inner diameter before heat-shrink (mm) EF003676 - Numeric
	06	Inner diameter after heat-shrink (mm) EF003677 - Numeric
	07	Max. wall thickness (mm) EF003678 - Numeric
	08	Seal width (depth) (mm) EF016100 - Numeric
	09	Diameter wall opening (mm) EF009478 - Range
	10	Width wall opening (mm) EF017454 - Range
	11	Min. distance between different transits (mm) EF017653 - Numeric
	12	Height wall opening (mm) EF017453 - Range
	13	Number of cables EF004419 - Numeric
	14	Mounting method EF000003 - Alphanumeric
	15	Gastight EF020030 - Logical
	16	Airtight EF020032 - Logical
	17	Watertight EF000017 - Logical
	18	Radon tight EF017210 - Logical
	19	Pressure (bar) EF025569 - Numeric
	20	Dismantling possible EF009480 - Logical
	21	Cable bundling possible EF009481 - Logical
	22	Reassignable EF017452 - Logical
	23	Shockproof against explosions EF017456 - Logical
	24	Certified for shipboard application EF013772 - Logical
	25	Fire resistance class according to DIN 4102-9 EFDE0060 - Alphanumeric
	26	Building sealing according to DIN 18533 EFDE0063 - Logical
	27	Building sealing according to DAfStb directive EFDE0064 - Logical

Synonyms

Front flange

Gel cast

Grommet

Heat-shrink

Heat-shrink wall duct

Modular partition (frame part)

Modular partition (module part)

Press ring seal

Pressure cast

Sealing flange for dowelling over core drillings and openings

Wall collar

Wall duct for cable

Wall lead-through

Wall transit

Wall transit for cable

Wall transit for cables and tubes
