Electronic switch EC001588

Published Domestic switching devices EG000013

/

Changes since v6

Features 26

1
Assembly arrangementEF000005

Choose one value

Basic elementBasic element with adaptor plateBasic element with housing topBasic element with complete housingBasic element with full cover plateBasic element with central cover plateControl elementIntermediate plugOther
2
ModelEF000010

Choose one value

MOSFETAuxiliary post (no longer used)RelayRelay and HVAC-relayTriacTronicOther
3
Type of loadEF001508

Choose one value

Inductive loadCapacitive loadUniversal and LED RetrofitResistive loadUniversalOther
4
Substation inputEF003876

Yes or no

YesNo
5
Light value memoryEF003867

Yes or no

YesNo
6
Applicable with buttonEF003910

Yes or no

YesNo
7
Applicable with movement sensorEF003906

Yes or no

YesNo
8
Applicable with presence indicatorEF003909

Yes or no

YesNo
9
Applicable with time switch/timerEF003911

Yes or no

YesNo
10
Applicable with transmission buttonEF003907

Yes or no

YesNo
11
Applicable with infrared buttonEF003908

Yes or no

YesNo
12
Mounting methodEF000003

Choose one value

Flush-mountedSurface mountedDRA (DIN-rail adaptor)Wall ductOther
13
MaterialEF002169

Choose one value

PlasticMetalGlassWoodStoneOther
14
Material qualityEF001257

Choose one value

DuroplastThermoplasticAluminiumStainless steelCopperSlateOther
15
Surface protectionEF000139

Choose one value

AnodisedDecorGalvanized (no longer used)LacqueredMetallicNano coatedSand-castOtherUntreated
16
Surface finishingEF006569

Choose one value

GlossyMattNot applicable (no longer used)
17
ColourEF000007

Choose one value

AluminiumAnthraciteBeigeBlueCyan (blue-green) (no longer used)BrownBronzeChromeStainless steelCream white (electro white) (no longer used)YellowGoldGreyGreenWoodBrassOrangePlatinumRedBlackSilverTitaniumWhiteNatural colour (no longer used)Other
18
RAL-number (similar)EF003882

A number
19
TransparentEF006243

Yes or no

YesNo
20
Nominal voltageEF000002

A number in V
21
FrequencyEF000416

A range, from and to, in Hz
22
Rated currentEF000227

A number in A
23
Switch capacityEF005233

A range, from and to, in W
24
Switch capacity HVACEF003887

A range, from and to, in W
25
Type of fasteningEF002442

Choose one value

Mounting with claw and screwMounting with screwMounting with clawClamp mountingGluingOther
26
Min. depth of built-in installation boxEF012278

A number in mm

Codes after each name are ETIM feature codes. Use them, not the names, in product data.
