Fitting with 1 connection
Code
EC003023Version
Group
Fittings, flanges and connectors (EG015540)Release
ETIM-8.0
Features
01 | Material connection 1 EF025616 - Alphanumeric | |
02 | Material quality connection 1 EF025618 - Alphanumeric | |
03 | Surface protection connection 1 EF010671 - Alphanumeric | |
04 | Surface treatment connection 1 EF010672 - Alphanumeric | |
05 | System specific EF025253 - Logical | |
06 | Nominal diameter connection 1 EF023193 - Alphanumeric | |
07 | Outer pipe diameter connection 1 (mm) EF020122 - Numeric | |
08 | Wall thickness, connection 1 (mm) EF021603 - Numeric | |
09 | Connection 1 EF000321 - Alphanumeric | |
10 | Main colour fitting EF016081 - Alphanumeric | |
11 | Max. operating pressure at 20 °C (bar) EF023116 - Numeric | |
12 | Contour code EF025254 - Alphanumeric | |
13 | Material sealing EF022606 - Alphanumeric | |
14 | Length of connection 1 (mm) EF020151 - Numeric | |
15 | Working length connection 1 (mm) EF020153 - Numeric | |
16 | Wrench width (mm) EF000177 - Numeric | |
17 | Wrench width union nut (mm) EF022259 - Numeric | |
18 | Medium temperature (continuous) (°C) EF023182 - Range | |
19 | Max. operating pressure at max. medium temperature (bar) EF014099 - Numeric | |
20 | Ring stiffness class EF010669 - Alphanumeric | |
21 | Standard Dimension Ratio (SDR) EF010670 - Numeric | |
22 | With sealing rings/gaskets EF020047 - Logical | |
23 | With drain valve EF020078 - Logical | |
24 | With de-aerator EF020079 - Logical | |
25 | Capped EF020028 - Logical | |
26 | FM quality mark EF021905 - Logical | |
27 | UL quality mark EF021907 - Logical | |
28 | ULC quality mark EF021908 - Logical | |
29 | LPCB quality mark EF021909 - Logical | |
30 | DIN-CERTCO certificate EFDE0006 - Logical | |
31 | VdS quality mark EFDE0010 - Logical | |
32 | With approval for TÜV EFDE0031 - Logical | |
33 | KIWA certified EFNL0001 - Logical | |
34 | Gastec QA mark EFNL0002 - Logical | |
35 | Type approval according to BBR/EKS EFSE0002 - Logical |
Synonyms
Blind plug
Cap
Cap round
Cap with hexagonal
Cap with square
Capillary fitting
Clamp fitting
Clamp fitting with 1 connection
Clamping-strip fitting with 1 connection
Cleaning screw cap
Click fitting
Click insert fitting with 1 connection
Compression fitting
Compression ring closing plate
Compression ring fitting with 1 connection
Dowel
End coupling
End stop
Endcap
Fitting with 1 connection
Glue coupling with 1 connector
Glue fitting with 1 connection
Glue socket with 1 connector
Grooved fitting with 1 connection
Hood
Laminated fitting with 1 connection
Malleable fittings
Plug
Plug with socket
Plug with square
Press cap
Press fitting
Press fitting with 1 connection
Push cap
Push fitting with 1 connection
Radiator stop
Shell
Shield
Slide cap
Slide dowel
Slide fitting
Slide plug
Sliding cap
Sliding dowel
Sliding fitting
Sliding fitting with 1 connection
Sliding plug
Soldered cap
Soldered fitting
Soldered fitting with 1 connection
Stop
Stub end
System fitting with 1 connection
Threaded fitting
Threaded fitting with 1 connection
Threaded plug
U2 end cap
Weld fitting
Welded-on fitting
Welded-on fitting with 1 connection
Welded-on plastic fitting with 1 connection
Welding fitting
