EC003731

Door fittings. Alternate square spindle; Anti-panic spindle; Profile pin; Solid spindle; Split pin; Square pin; Square solid spindle; Square spindle for doors/windows; Startec square spindle; Switch pin; Switch spindle

Code:

Version:

Group:

Door fittings

EG020004

Release:

ETIM-9.0

Features

	01		Model EF000010 - Alphanumeric
	02		Suitable for doors EF014909 - Logical
	03		Suitable for window EF012143 - Logical
	04		Material EF002169 - Alphanumeric
	05		Surface protection EF000139 - Alphanumeric
	06		Cross section EF013108 - Alphanumeric
	07		Length (mm) EF001438 - Numeric
	08		Length of stepped part (mm) EF013109 - Numeric
	09		With clamping spring EF013110 - Logical
	10		Prepared for threaded pin EF013111 - Logical
	11		With expanding pin EF013113 - Logical
	12		With set screw EF006217 - Logical
	13		Suitable according to EN 179 EF012928 - Logical

Synonyms

Alternate square spindle

Anti-panic spindle

Profile pin

Solid spindle

Split pin

Square pin

Square solid spindle

Square spindle for doors/windows

Startec square spindle

Switch pin

Switch spindle

Square spindle for doors/windows

EC003731

Model

Suitable for doors

Suitable for window

Material

Surface protection

Cross section

Length (mm)

Length of stepped part (mm)

With clamping spring

Prepared for threaded pin

With expanding pin

With set screw

Suitable according to EN 179
