Pipeline strainer

Code

EC010151

Version

Group

Filters/separators (EG015140)

Release

ETIM-9.0

2BA

RSK

InstallData

Sahkonumerot

Features

	01	Shape EF000051 - Alphanumeric
	02	Suitable for medium EF021416 - Alphanumeric
	03	Housing material EF001596 - Alphanumeric
	04	Material quality EF001257 - Alphanumeric
	05	Surface protection EF000139 - Alphanumeric
	06	Nominal diameter EF023191 - Alphanumeric
	07	Material sealing EF022606 - Alphanumeric
	08	Material filter element EF020367 - Alphanumeric
	09	Outer pipe diameter all connections (mm) EF020126 - Numeric
	10	Connection EF000443 - Alphanumeric
	11	Cover attachment EF004586 - Alphanumeric
	12	With coupling EF022615 - Logical
	13	Filter grade (µm) EF014010 - Numeric
	14	Exchangeable filter EF025361 - Logical
	15	With permanent magnet EF020366 - Logical
	16	Internally lined EF023820 - Alphanumeric
	17	Article compression class EF020007 - Alphanumeric
	18	Flange compression class EF020149 - Alphanumeric
	19	Flange standard EF021694 - Alphanumeric
	20	Max. operating pressure (bar) EF020449 - Numeric
	21	Max. pressure difference at 20 °C (bar) EF020150 - Numeric
	22	Medium temperature (continuous) (°C) EF023182 - Range
	23	With drain possibility (connection) EF022470 - Logical
	24	Kvs value EF022466 - Numeric
	25	Length (mm) EF001438 - Numeric
	26	Length of connection 1 (mm) EF020151 - Numeric
	27	Working length connection 1 (mm) EF020153 - Numeric
	28	Length of connection 2 (mm) EF020152 - Numeric
	29	Working length connection 2 (mm) EF020154 - Numeric
	30	Height (mm) EF000040 - Numeric
	31	Filter housing height (mm) EF021682 - Numeric
	32	Diffusor EF000647 - Logical
	33	KIWA certified EFNL0001 - Logical
	34	Gastec QA mark EFNL0002 - Logical

Synonyms

Compressed air filter

Conical strainer

CV filter

Dirt separator

Dirt trap

Filter

Gas filter

Oil filter

Pipe filter

Pipeline strainer

Separator

Sieve

Steam filter

Strainer

Tee strainer

Water filter

Y filter

Y type filter

Y-filter

Y-strainer
