Wall plate continuous straight MC000026
Features 41
Class features
- 1
ShapeEF000051
Choose one value
Continuous straight - 2
Mutual angle of the holesEF010156
A number in ° · a in drawing
- 5
Diameter wall plateEF010155
A number in mm · D in drawing
- 16
Connection heightEF022561
A number in mm · h in drawing
- 17
Distance wall plate to connectionEF010696
A number in mm · H1 in drawing
- 22
Length from wall plateEF020417
A number in mm · Le1 in drawing
- 23
Number of holesEF026414
A number · n in drawing
- 29
Radius to centre holesEF010157
A number in mm · r in drawing
Port 1
- 3
Height screw glandEF010040
A number in mm · C1 in drawing
- 6
Nominal diameterEF023191
Choose one value · DN1 in drawing
3/8 inch (10)1/2 inch (15)3/4 inch (20)1 inch (25)DN 10DN 12DN 15DN 18DN 20DN 25DN 32 - 9
Outer pipe diameter connectionEF020208
A number in mm · Do1 in drawing
- 12
Rim diameterEF010037
A number in mm · Dr1 in drawing
- 14
Height screw gland edgeEF010516
A number in mm · g1 in drawing
- 18
Distance to edgeEF010519
A number in mm · j1 in drawing
- 20
Length of connection 1EF020151
A number in mm · L1 in drawing
- 24
Sleeve length (no longer used)EF010520
A number in mm · P1 in drawing
- 27
Length gusset/threadEF010521
A number in mm · Q1 in drawing
- 30
Wall thickness connectionEF010546
A number in mm · s1 in drawing
- 32
Wrench width union nutEF022259
A number in mm · SLW1 in drawing
- 34
Rim thicknessEF010038
A number in mm · t1 in drawing
- 36
Working length connection 1EF020153
A number in mm · Z1 in drawing
- 39
ConnectionEF000443
Choose one value
Internal thread conical (NPT)Internal thread cylindrical BSPP-G (ISO 228-1)Internal thread conical BSPT-Rc (ISO 7-1 / EN 10226-1)Internal thread cylindrical BSPT-Rp (ISO 7-1 / EN 10226-1)Internal thread flare (UNF)Internal thread metricExternal threadInsert (push-fitting)Clamp connectionCompression ring
Port 2
- 4
Height screw glandEF010040
A number in mm · C2 in drawing
- 7
Nominal diameterEF023191
Choose one value · DN2 in drawing
3/8 inch (10)1/2 inch (15)3/4 inch (20)1 inch (25)DN 10DN 12DN 15DN 18DN 20DN 25DN 32 - 10
Outer pipe diameter connectionEF020208
A number in mm · Do2 in drawing
- 13
Rim diameterEF010037
A number in mm · Dr2 in drawing
- 15
Height screw gland edgeEF010516
A number in mm · g2 in drawing
- 19
Distance to edgeEF010519
A number in mm · j2 in drawing
- 21
Length of connection 2EF020152
A number in mm · L2 in drawing
- 25
Sleeve length (no longer used)EF010520
A number in mm · P2 in drawing
- 28
Length gusset/threadEF010521
A number in mm · Q2 in drawing
- 31
Wall thickness connectionEF010546
A number in mm · s2 in drawing
- 33
Wrench width union nutEF022259
A number in mm · SLW2 in drawing
- 35
Rim thicknessEF010038
A number in mm · t2 in drawing
- 37
Working length connection 2EF020154
A number in mm · Z2 in drawing
- 40
ConnectionEF000443
Choose one value
Internal thread conical (NPT)Internal thread cylindrical BSPP-G (ISO 228-1)Internal thread conical BSPT-Rc (ISO 7-1 / EN 10226-1)Internal thread cylindrical BSPT-Rp (ISO 7-1 / EN 10226-1)Internal thread flare (UNF)Internal thread metricExternal threadInsert (push-fitting)Clamp connectionCompression ring
Port 3
- 8
Thread size tap connectionEF010681
Choose one value · DN3 in drawing
1/8 inch1/4 inch3/8 inch1/2 inch3/4 inch1 inch1 1/4 inch1 1/2 inch2 inch - 11
Outer pipe diameter connectionEF020208
A number in mm · Do3 in drawing
- 26
Sleeve length (no longer used)EF010520
A number in mm · P3 in drawing
- 38
Working length connection 3EF020160
A number in mm · Z3 in drawing
- 41
ConnectionEF000443
Choose one value
Internal thread conical (NPT)Internal thread cylindrical BSPP-G (ISO 228-1)Internal thread conical BSPT-Rc (ISO 7-1 / EN 10226-1)Internal thread cylindrical BSPT-Rp (ISO 7-1 / EN 10226-1)Internal thread flare (UNF)Internal thread metric
