3-part coupling (straight) MC000029

Published Piping - Pipe fittings, flanges and adaptors MG000023

/

Features 25

Class features

1
ShapeEF000051

Choose one value

Straight
2
ModelEF000010

Choose one value

3-part
11
Height screw gland 1EF010702

A number in mm · hw-1 in drawing
12
Height screw gland 2EF010703

A number in mm · hw-2 in drawing
17
Wrench width 1EF010807

A number in mm · SW-1 in drawing
18
Wrench width 2EF010808

A number in mm · SW-2 in drawing

Port 1

4
Nominal diameter connection 1EF023193

Choose one value · DN1 in drawing

1/8 inch (6)1/4 inch (8)3/8 inch (10)1/2 inch (15)3/4 inch (20)1 inch (25)1 1/8 inch1 1/4 inch (32)1 5/16 inch1 3/8 inch1 1/2 inch (40)1 3/4 inch1 7/8 inch2 inch (50)2 3/8 inch2 1/2 inch (65)3 inch (80)3 1/2 inch4 inch (100)5 inch (125)6 inch (150)7 inch (175)8 inch (200)10 inch (250)12 inch (300)DN 6DN 8DN 10DN 12DN 15DN 18DN 20DN 25DN 32DN 40DN 50DN 60DN 65DN 70DN 75DN 80DN 90DN 100DN 110DN 125DN 150DN 160DN 175DN 200DN 250DN 300DN 315DN 350DN 400DN 450DN 500DN 600DN 630DN 700DN 800DN 900DN 1000DN 1200DN 1400DN 1600DN 1800DN 2000M8 x 1.0M10 x 1.0M10 x 1.25M12 x 1.25M12 x 1.5M14 x 1.5M16 x 1.5M18 x 1.5M20 x 1.5M22 x 1.5M24 x 1.5M24 x 2.0M26 x 1.5M27 x 2.0M30 x 2.0M36 x 3.0M45 x 2.0
6
Outer pipe diameter connection 1EF020122

A number in mm · Do1 in drawing
8
Rim diameterEF010037

A number in mm · Dr1 in drawing
13
Distance to edgeEF010519

A number in mm · j1 in drawing
15
Length of connection 1EF020151

A number in mm · L1 in drawing
20
Rim thicknessEF010038

A number in mm · t1 in drawing
22
Working length connection 1EF020153

A number in mm · Z1 in drawing
24
Connection 1EF000321

Choose one value

Internal thread cylindrical BSPP-G (ISO 228-1)Internal thread metricInternal thread conical (NPT)Internal thread conical BSPT-Rc (ISO 7-1 / EN 10226-1)Internal thread cylindrical BSPT-Rp (ISO 7-1 / EN 10226-1)Internal thread flare (UNF)External thread conical (NPT)External thread metricExternal thread conical BSPT-R (ISO 7-1 / EN 10226-1)External thread cylindrical BSPP-G (ISO 228-1)External thread flare (UNF)Insert (push-fitting)Soldered endSoldered sleeveCompression ringClamp connectionGlued endGlued sleevePress sleeveSlide endSlide sleeve

Port 2

3
Height screw glandEF010040

A number in mm · C2 in drawing
5
Nominal diameter connection 2EF020052

Choose one value · DN2 in drawing

1/8 inch (6)1/4 inch (8)3/8 inch (10)1/2 inch (15)3/4 inch (20)1 inch (25)1 1/8 inch1 1/4 inch (32)1 5/16 inch1 3/8 inch1 1/2 inch (40)1 3/4 inch1 7/8 inch2 inch (50)2 3/8 inch2 1/2 inch (65)3 inch (80)3 1/2 inch4 inch (100)5 inch (125)6 inch (150)7 inch (175)8 inch (200)10 inch (250)12 inch (300)DN 6DN 8DN 10DN 12DN 15DN 18DN 20DN 25DN 32DN 40DN 50DN 60DN 65DN 70DN 75DN 80DN 90DN 100DN 110DN 125DN 150DN 160DN 175DN 200DN 250DN 300DN 315DN 350DN 400DN 450DN 500DN 600DN 630DN 700DN 800DN 900DN 1000DN 1200DN 1400DN 1600DN 1800DN 2000M8 x 1.0M10 x 1.0M10 x 1.25M12 x 1.25M12 x 1.5M14 x 1.5M16 x 1.5M18 x 1.5M20 x 1.5M22 x 1.5M24 x 1.5M24 x 2.0M26 x 1.5M27 x 2.0M30 x 2.0M36 x 3.0M45 x 2.0
7
Outer pipe diameter connection 2EF020123

A number in mm · Do2 in drawing
9
Rim diameterEF010037

A number in mm · Dr2 in drawing
10
Height screw gland edgeEF010516

A number in mm · g2 in drawing
14
Distance to edgeEF010519

A number in mm · j2 in drawing
16
Length of connection 2EF020152

A number in mm · L2 in drawing
19
Wrench width union nutEF022259

A number in mm · SLW2 in drawing
21
Rim thicknessEF010038

A number in mm · t2 in drawing
23
Working length connection 2EF020154

A number in mm · Z2 in drawing
25
Connection 2EF000322

Choose one value

Internal thread cylindrical BSPP-G (ISO 228-1)Internal thread metricInternal thread conical (NPT)Internal thread conical BSPT-Rc (ISO 7-1 / EN 10226-1)Internal thread cylindrical BSPT-Rp (ISO 7-1 / EN 10226-1)Internal thread flare (UNF)External thread conical (NPT)External thread metricExternal thread conical BSPT-R (ISO 7-1 / EN 10226-1)External thread cylindrical BSPP-G (ISO 228-1)External thread flare (UNF)Insert (push-fitting)Soldered endSoldered sleeveCompression ringClamp connectionGlued endGlued sleevePress sleeveSlide endSlide sleeve

Codes after each name are ETIM feature codes. Use them, not the names, in product data.
