Solar heater tank (return flow) round
Code
MC000044Version
Group
Hydronic - Domestic home water heaters and storage (MG000045)Release
Drawing
Features
28 | D | Diameter (mm) EF000551 - Numeric | |
56 | DM | Diameter manhole (mm) EF010868 - Numeric | |
84 | H | Height (mm) EF000040 - Numeric | |
94 | HM | Height man hole (mm) EF010749 - Numeric |
Features port 1
01 | a1 | Angle to first bolt hole (°) EF010524 - Numeric | |
10 | a1-1 | Angle connection (°) EF010747 - Numeric | |
19 | b1 | Thickness flange (incl. sealing edge) (mm) EF010525 - Numeric | |
29 | D1 | Outer diameter of flange (mm) EF021531 - Numeric | |
38 | d2-1 | Diameter bolt hole (mm) EF021780 - Numeric | |
47 | d4-1 | Diameter sealing edge (mm) EF010527 - Numeric | |
57 | DN1 | Nominal diameter cold tap water EF020013 - Alphanumeric | |
66 | Do1 | Outer pipe diameter cold tap water (mm) EF020499 - Numeric | |
75 | f1 | Thickness sealing edge (mm) EF010528 - Numeric | |
85 | H1 | Distance bottom side to connection (mm) EF010748 - Numeric | |
95 | k1 | Pitch circle (mm) EF021643 - Numeric | |
104 | L1 | Connection length (mm) EF022519 - Numeric | |
113 | n1 | Number of bolt holes EF021779 - Numeric | |
122 | P1 | Sleeve length (mm) EF010520 - Numeric | |
131 | Q1 | Length gusset/thread (mm) EF010521 - Numeric | |
140 | s1 | Wall thickness connection (mm) EF010546 - Numeric | |
149 | Z1 | Working length (mm) EF006318 - Numeric | |
158 | Cold tap water connection EF021386 - Alphanumeric |
Features port 2
02 | a2 | Angle to first bolt hole (°) EF010524 - Numeric | |
11 | a1-2 | Angle connection (°) EF010747 - Numeric | |
20 | b2 | Thickness flange (incl. sealing edge) (mm) EF010525 - Numeric | |
30 | D2 | Outer diameter of flange (mm) EF021531 - Numeric | |
39 | d2-2 | Diameter bolt hole (mm) EF021780 - Numeric | |
48 | d4-2 | Diameter sealing edge (mm) EF010527 - Numeric | |
58 | DN2 | Nominal diameter hot tap water EF010896 - Alphanumeric | |
67 | Do2 | Outer pipe diameter hot tap water (mm) EF020504 - Numeric | |
76 | f2 | Thickness sealing edge (mm) EF010528 - Numeric | |
86 | H2 | Distance bottom side to connection (mm) EF010748 - Numeric | |
96 | k2 | Pitch circle (mm) EF021643 - Numeric | |
105 | L2 | Connection length (mm) EF022519 - Numeric | |
114 | n2 | Number of bolt holes EF021779 - Numeric | |
123 | P2 | Sleeve length (mm) EF010520 - Numeric | |
132 | Q2 | Length gusset/thread (mm) EF010521 - Numeric | |
141 | s2 | Wall thickness connection (mm) EF010546 - Numeric | |
150 | Z2 | Working length (mm) EF006318 - Numeric | |
159 | Hot tap water connection EF021387 - Alphanumeric |
Features port 3
03 | a3 | Angle to first bolt hole (°) EF010524 - Numeric | |
12 | a1-3 | Angle connection (°) EF010747 - Numeric | |
21 | b3 | Thickness flange (incl. sealing edge) (mm) EF010525 - Numeric | |
31 | D3 | Outer diameter of flange (mm) EF021531 - Numeric | |
40 | d2-3 | Diameter bolt hole (mm) EF021780 - Numeric | |
49 | d4-3 | Diameter sealing edge (mm) EF010527 - Numeric | |
59 | DN3 | Nominal diameter drain connection EF010881 - Alphanumeric | |
68 | Do3 | Outer pipe diameter drainage connection (mm) EF021390 - Numeric | |
77 | f3 | Thickness sealing edge (mm) EF010528 - Numeric | |
87 | H3 | Distance bottom side to connection (mm) EF010748 - Numeric | |
97 | k3 | Pitch circle (mm) EF021643 - Numeric | |
106 | L3 | Connection length (mm) EF022519 - Numeric | |
115 | n3 | Number of bolt holes EF021779 - Numeric | |
124 | P3 | Sleeve length (mm) EF010520 - Numeric | |
133 | Q3 | Length gusset/thread (mm) EF010521 - Numeric | |
142 | s3 | Wall thickness connection (mm) EF010546 - Numeric | |
151 | Z3 | Working length (mm) EF006318 - Numeric | |
160 | Connection, drainage connection EF021391 - Alphanumeric |
Features port 4
04 | a4 | Angle to first bolt hole (°) EF010524 - Numeric | |
13 | a1-4 | Angle connection (°) EF010747 - Numeric | |
22 | b4 | Thickness flange (incl. sealing edge) (mm) EF010525 - Numeric | |
32 | D4 | Outer diameter of flange (mm) EF021531 - Numeric | |
41 | d2-4 | Diameter bolt hole (mm) EF021780 - Numeric | |
50 | d4-4 | Diameter sealing edge (mm) EF010527 - Numeric | |
60 | DN4 | Nominal diameter primary connection EF010882 - Alphanumeric | |
69 | Do4 | Outer pipe diameter primary connection (mm) EF022025 - Numeric | |
78 | f4 | Thickness sealing edge (mm) EF010528 - Numeric | |
88 | H4 | Distance bottom side to connection (mm) EF010748 - Numeric | |
98 | k4 | Pitch circle (mm) EF021643 - Numeric | |
107 | L4 | Connection length (mm) EF022519 - Numeric | |
116 | n4 | Number of bolt holes EF021779 - Numeric | |
125 | P4 | Sleeve length (mm) EF010520 - Numeric | |
134 | Q4 | Length gusset/thread (mm) EF010521 - Numeric | |
143 | s4 | Wall thickness connection (mm) EF010546 - Numeric | |
152 | Z4 | Working length (mm) EF006318 - Numeric | |
161 | Primary connection EF022024 - Alphanumeric |
Features port 5
05 | a5 | Angle to first bolt hole (°) EF010524 - Numeric | |
14 | a1-5 | Angle connection (°) EF010747 - Numeric | |
23 | b5 | Thickness flange (incl. sealing edge) (mm) EF010525 - Numeric | |
33 | D5 | Outer diameter of flange (mm) EF021531 - Numeric | |
42 | d2-5 | Diameter bolt hole (mm) EF021780 - Numeric | |
51 | d4-5 | Diameter sealing edge (mm) EF010527 - Numeric | |
61 | DN5 | Nominal diameter reheater EF010883 - Alphanumeric | |
70 | Do5 | Outer pipe diameter reheater (mm) EF022738 - Numeric | |
79 | f5 | Thickness sealing edge (mm) EF010528 - Numeric | |
89 | H5 | Distance bottom side to connection (mm) EF010748 - Numeric | |
99 | k5 | Pitch circle (mm) EF021643 - Numeric | |
108 | L5 | Connection length (mm) EF022519 - Numeric | |
117 | n5 | Number of bolt holes EF021779 - Numeric | |
126 | P5 | Sleeve length (mm) EF010520 - Numeric | |
135 | Q5 | Length gusset/thread (mm) EF010521 - Numeric | |
144 | s5 | Wall thickness connection (mm) EF010546 - Numeric | |
153 | Z5 | Working length (mm) EF006318 - Numeric | |
162 | Connection, reheater EF022099 - Alphanumeric |
Features port 6
06 | a6 | Angle to first bolt hole (°) EF010524 - Numeric | |
15 | a1-6 | Angle connection (°) EF010747 - Numeric | |
24 | b6 | Thickness flange (incl. sealing edge) (mm) EF010525 - Numeric | |
34 | D6 | Outer diameter of flange (mm) EF021531 - Numeric | |
43 | d2-6 | Diameter bolt hole (mm) EF021780 - Numeric | |
52 | d4-6 | Diameter sealing edge (mm) EF010527 - Numeric | |
62 | DN6 | Nominal diameter connection EF025620 - Alphanumeric | |
71 | Do6 | Outer pipe diameter connection (mm) EF020208 - Numeric | |
80 | f6 | Thickness sealing edge (mm) EF010528 - Numeric | |
90 | H6 | Distance bottom side to connection (mm) EF010748 - Numeric | |
100 | k6 | Pitch circle (mm) EF021643 - Numeric | |
109 | L6 | Connection length (mm) EF022519 - Numeric | |
118 | n6 | Number of bolt holes EF021779 - Numeric | |
127 | P6 | Sleeve length (mm) EF010520 - Numeric | |
136 | Q6 | Length gusset/thread (mm) EF010521 - Numeric | |
145 | s6 | Wall thickness connection (mm) EF010546 - Numeric | |
154 | Z6 | Working length (mm) EF006318 - Numeric | |
163 | Connection EF000443 - Alphanumeric |
Features port 7
07 | a7 | Angle to first bolt hole (°) EF010524 - Numeric | |
16 | a1-7 | Angle connection (°) EF010747 - Numeric | |
25 | b7 | Thickness flange (incl. sealing edge) (mm) EF010525 - Numeric | |
35 | D7 | Outer diameter of flange (mm) EF021531 - Numeric | |
44 | d2-7 | Diameter bolt hole (mm) EF021780 - Numeric | |
53 | d4-7 | Diameter sealing edge (mm) EF010527 - Numeric | |
63 | DN7 | Nominal diameter connection EF025620 - Alphanumeric | |
72 | Do7 | Outer pipe diameter connection (mm) EF020208 - Numeric | |
81 | f7 | Thickness sealing edge (mm) EF010528 - Numeric | |
91 | H7 | Distance bottom side to connection (mm) EF010748 - Numeric | |
101 | k7 | Pitch circle (mm) EF021643 - Numeric | |
110 | L7 | Connection length (mm) EF022519 - Numeric | |
119 | n7 | Number of bolt holes EF021779 - Numeric | |
128 | P7 | Sleeve length (mm) EF010520 - Numeric | |
137 | Q7 | Length gusset/thread (mm) EF010521 - Numeric | |
146 | s7 | Wall thickness connection (mm) EF010546 - Numeric | |
155 | Z7 | Working length (mm) EF006318 - Numeric | |
164 | Connection EF000443 - Alphanumeric |
Features port 8
08 | a8 | Angle to first bolt hole (°) EF010524 - Numeric | |
17 | a1-8 | Angle connection (°) EF010747 - Numeric | |
26 | b8 | Thickness flange (incl. sealing edge) (mm) EF010525 - Numeric | |
36 | D8 | Outer diameter of flange (mm) EF021531 - Numeric | |
45 | d2-8 | Diameter bolt hole (mm) EF021780 - Numeric | |
54 | d4-8 | Diameter sealing edge (mm) EF010527 - Numeric | |
64 | DN8 | Nominal diameter connection EF025620 - Alphanumeric | |
73 | Do8 | Outer pipe diameter connection (mm) EF020208 - Numeric | |
82 | f8 | Thickness sealing edge (mm) EF010528 - Numeric | |
92 | H8 | Distance bottom side to connection (mm) EF010748 - Numeric | |
102 | k8 | Pitch circle (mm) EF021643 - Numeric | |
111 | L8 | Connection length (mm) EF022519 - Numeric | |
120 | n8 | Number of bolt holes EF021779 - Numeric | |
129 | P8 | Sleeve length (mm) EF010520 - Numeric | |
138 | Q8 | Length gusset/thread (mm) EF010521 - Numeric | |
147 | s8 | Wall thickness connection (mm) EF010546 - Numeric | |
156 | Z8 | Working length (mm) EF006318 - Numeric | |
165 | Connection EF000443 - Alphanumeric |
Features port 9
09 | a9 | Angle to first bolt hole (°) EF010524 - Numeric | |
18 | a1-9 | Angle connection (°) EF010747 - Numeric | |
27 | b9 | Thickness flange (incl. sealing edge) (mm) EF010525 - Numeric | |
37 | D9 | Outer diameter of flange (mm) EF021531 - Numeric | |
46 | d2-9 | Diameter bolt hole (mm) EF021780 - Numeric | |
55 | d4-9 | Diameter sealing edge (mm) EF010527 - Numeric | |
65 | DN9 | Nominal diameter connection EF025620 - Alphanumeric | |
74 | Do9 | Outer pipe diameter connection (mm) EF020208 - Numeric | |
83 | f9 | Thickness sealing edge (mm) EF010528 - Numeric | |
93 | H9 | Distance bottom side to connection (mm) EF010748 - Numeric | |
103 | k9 | Pitch circle (mm) EF021643 - Numeric | |
112 | L9 | Connection length (mm) EF022519 - Numeric | |
121 | n9 | Number of bolt holes EF021779 - Numeric | |
130 | P9 | Sleeve length (mm) EF010520 - Numeric | |
139 | Q9 | Length gusset/thread (mm) EF010521 - Numeric | |
148 | s9 | Wall thickness connection (mm) EF010546 - Numeric | |
157 | Z9 | Working length (mm) EF006318 - Numeric | |
166 | Connection EF000443 - Alphanumeric |
Related productclasses
Synonyms
Solar heater tank (return flow) round
