Ventilation valve
MC000097 / v3
Code
MC000097Version
3
Group
Ventilation - Air terminals (inlet/extract) (MG000004)Release
1 / 3
Drawing
Features
01 | Shape EF000051 - Alphanumeric | ||
02 | Air supply valve EF022318 - Logical | ||
03 | Air extraction valve EF022317 - Logical | ||
04 | DN | Nominal duct diameter connection (mm) EF022923 - Numeric | |
05 | Do | Front diameter (mm) EF022765 - Numeric | |
06 | H | Built-in depth (mm) EF000218 - Numeric | |
07 | H1 | Front height (mm) EF022768 - Numeric | |
08 | L | Front length (mm) EF022772 - Numeric | |
09 | s | Material thickness (mm) EF000386 - Numeric | |
10 | W | Front width (mm) EF022764 - Numeric |
Features port 1
11 | Connection EF000443 - Alphanumeric |
Related productclasses
Synonyms
Ventilation valve
