Mounting materials for pipes and ducts. Support/profile rail; Support/profile rail (C-profile, singular)

Code:

Version:

Group:

Mounting materials for pipes and ducts

MG000031

Drawing

Features

01		Profile shape EF005179 - Alphanumeric
02		Model EF000010 - Alphanumeric
03	H	Height (mm) EF000040 - Numeric
04	L	Length (mm) EF001438 - Numeric
05	L1	Length 1 (mm) EF021554 - Numeric
06	L2	Length 2 (mm) EF021555 - Numeric
07	L3	Length 3 (mm) EF021750 - Numeric
08	L4	Length 4 (mm) EF010951 - Numeric
09	L5	Length 5 (mm) EF010961 - Numeric
10	s	Material thickness (mm) EF000386 - Numeric
11	W	Width (mm) EF000008 - Numeric
12	W1	Width 1 (mm) EF023087 - Numeric

Related productclasses

EC000386/6

EC000386/7

Synonyms

Support/profile rail

Support/profile rail (C-profile, singular)

Support/profile rail (C-profile, singular)
