Shower tray (square/rectangular)
MC000294 / v2
Code
MC000294Version
2
Group
Water - Sanitary fixtures and appliances (MG000039)Release
1 / 2
Drawing
Features
01 | Shape EF000051 - Alphanumeric | ||
03 | H | Height (mm) EF000040 - Numeric | |
04 | H2 | Edge height (mm) EF021511 - Numeric | |
05 | L | Length (mm) EF001438 - Numeric | |
07 | Le1 | Rim thickness (mm) EF010038 - Numeric | |
08 | Le3 | Length to centre drain (mm) EF011466 - Numeric | |
09 | W | Width (mm) EF000008 - Numeric | |
10 | W2 | Width to centre drain (mm) EF011513 - Numeric |
Features port 1
02 | AG | Diameter of drain hole (mm) EF020710 - Numeric | |
06 | L1 | Connection length (mm) EF022519 - Numeric |
Related productclasses
Synonyms
Shower tray (square)
Shower tray (square/rectangular)
