Single-walled flue gas attachment, 3 connections
Code
MC000432Version
2
Group
Hydronic - Flue gas and combustion air systems (MG000024)Release
Drawing
Features
01 | Model EF000010 - Alphanumeric | ||
05 | a1 | Angle 1 (°) EF010888 - Numeric | |
06 | a2 | Angle 2 (°) EF010889 - Numeric |
Features port 1
02 | Connection EF000443 - Alphanumeric | ||
07 | Dd1 | Duct diameter (mm) EF021896 - Numeric | |
10 | L1 | Connection length (mm) EF022519 - Numeric | |
13 | Z1 | Working length connection (mm) EF016476 - Numeric |
Features port 2
03 | Connection EF000443 - Alphanumeric | ||
08 | Dd2 | Duct diameter (mm) EF021896 - Numeric | |
11 | L2 | Connection length (mm) EF022519 - Numeric | |
14 | Z2 | Working length connection (mm) EF016476 - Numeric |
Features port 3
04 | Connection EF000443 - Alphanumeric | ||
09 | Dd3 | Duct diameter (mm) EF021896 - Numeric | |
12 | L3 | Connection length (mm) EF022519 - Numeric | |
15 | Z3 | Working length connection (mm) EF016476 - Numeric |
Related productclasses
Synonyms
Flue gas T-piece
Single-walled flue gas attachment with 3 connections
Single-walled flue gas attachment, 3 connections
