Electric actuator with damper blade round air duct MC000447

Published
Hydronic - Valves and control components MG000042

Features 12

  1. 1

    Diameter feed-through 1EF011009

    A number in mm · D1 in drawing

  2. 2

    Diameter feed-through 2EF011010

    A number in mm · D2 in drawing

  3. 3

    Suitable for nominal duct diameterEF020806

    A number in mm · DN in drawing

  4. 4

    HeightEF000040

    A number in mm · H in drawing

  5. 5

    Height 2EF010006

    A number in mm · H2 in drawing

  6. 6

    LengthEF001438

    A number in mm · L in drawing

  7. 7

    Built-in lengthEF004265

    A number in mm · L1 in drawing

  8. 8

    Length 2EF021555

    A number in mm · L2 in drawing

  9. 9

    Length 3EF021750

    A number in mm · L3 in drawing

  10. 10

    Centre-to-centre holesEF010731

    A number in mm · S in drawing

  11. 11

    WidthEF000008

    A number in mm · W in drawing

  12. 12

    DiameterEF000551

    A number in mm · D in drawing

Codes after each name are ETIM feature codes. Use them, not the names, in product data.
