Mounting G-rail MC000494

Published
Supports - Installation support hardware MG000031

Features 14

  1. 1

    Height (large)EF014724

    A number in mm · H1 in drawing

  2. 2

    Height (small)EF014725

    A number in mm · H2 in drawing

  3. 3

    LengthEF001438

    A number in mm · L in drawing

  4. 4

    Length 1EF021554

    A number in mm · L1 in drawing

  5. 5

    Length 2EF021555

    A number in mm · L2 in drawing

  6. 6

    Length 3EF021750

    A number in mm · L3 in drawing

  7. 7

    Length 4EF010951

    A number in mm · L4 in drawing

  8. 8

    Length 5EF010961

    A number in mm · L5 in drawing

  9. 9

    RadiusEF020621

    A number in mm · R1 in drawing

  10. 10

    Material thicknessEF000386

    A number in mm · s in drawing

  11. 11

    WidthEF000008

    A number in mm · W in drawing

  12. 12

    Slit widthEF005247

    A number in mm · W1 in drawing

  13. 13

    Width 2EF023088

    A number in mm · W2 in drawing

  14. 14

    Width 3EF010999

    A number in mm · W3 in drawing
