End plate for wall duct
Code
MC000520Version
1
Group
Electrical - Trunking and surface raceways (MG000053)Release
Drawing
Features
01 | H | Height (mm) EF000040 - Numeric | |
02 | H1 | Height 1 (mm) EF010005 - Numeric | |
03 | H2 | Height 2 (mm) EF010006 - Numeric | |
04 | W | Width (mm) EF000008 - Numeric | |
05 | W1 | Width 1 (mm) EF023087 - Numeric | |
06 | W2 | Width 2 (mm) EF023088 - Numeric | |
07 | W3 | Width 3 (mm) EF010999 - Numeric | |
08 | W4 | Width 4 (mm) EF011000 - Numeric | |
09 | D | Depth (mm) EF000049 - Numeric | |
10 | D1 | Depth 1 (mm) EF010952 - Numeric |
Related productclasses
Synonyms
End plate for wall duct
Wall connection blind for wall duct
