Ventilator, heat recovery, wall-mounted MC000346

A wall-mounted residential heat recovery ventilation unit exchanging heat between supply and exhaust air streams.

Under construction
Ventilation and flue gas components MG000043

Features 79

Class features

  1. 1

    Suitable for wall mountingEF000664

    Yes or no

    YesNo
  2. 2

    Position electrical connectionEF010979

    A coordinate in mm · CA9 in drawing

  3. 3

    DepthEF000049

    A number in mm · D in drawing

  4. 4

    HeightEF000040

    A number in mm · H in drawing

  5. 5

    Height to centre suspension 1EF011571

    A number in mm · H1 in drawing

  6. 6

    Height to centre suspension 2EF011572

    A number in mm · H2 in drawing

  7. 7

    Length to centre suspension 1EF011573

    A number in mm · Le1 in drawing

  8. 8

    Length to centre suspension 2EF011574

    A number in mm · Le2 in drawing

  9. 9

    WidthEF000008

    A number in mm · W in drawing

Port 1

  1. 10

    ConnectionEF000443

    Choose one value

    Insert endDuct end
  2. 11

    Connection purpose according to EN 16798-3EF015774

    Choose one value

    EHA
  3. 12

    Position connectionEF011006

    A coordinate in mm · CA1 in drawing

  4. 13

    Nominal duct diameter connectionEF022923

    A number in mm · DN1 in drawing

  5. 14

    Outer pipe diameter connectionEF020208

    A number in mm · Do1 in drawing

  6. 15

    Directional vector connectionEF011005

    A coordinate · DV1 in drawing

  7. 16

    Sleeve length (no longer used)EF010520

    A number in mm · P1 in drawing

  8. 17

    Length gusset/threadEF010521

    A number in mm · Q1 in drawing

  9. 18

    Wall thickness connectionEF010546

    A number in mm · s1 in drawing

Port 2

  1. 19

    ConnectionEF000443

    Choose one value

    Insert endDuct end
  2. 20

    Connection purpose according to EN 16798-3EF015774

    Choose one value

    ODA
  3. 21

    Position connectionEF011006

    A coordinate in mm · CA2 in drawing

  4. 22

    Nominal duct diameter connectionEF022923

    A number in mm · DN2 in drawing

  5. 23

    Outer pipe diameter connectionEF020208

    A number in mm · Do2 in drawing

  6. 24

    Directional vector connectionEF011005

    A coordinate · DV2 in drawing

  7. 25

    Sleeve length (no longer used)EF010520

    A number in mm · P2 in drawing

  8. 26

    Length gusset/threadEF010521

    A number in mm · Q2 in drawing

  9. 27

    Wall thickness connectionEF010546

    A number in mm · s2 in drawing

Port 3

  1. 28

    ConnectionEF000443

    Choose one value

    Insert endDuct end
  2. 29

    Connection purpose according to EN 16798-3EF015774

    Choose one value

    ETA
  3. 30

    Position connectionEF011006

    A coordinate in mm · CA3 in drawing

  4. 31

    Nominal duct diameter connectionEF022923

    A number in mm · DN3 in drawing

  5. 32

    Outer pipe diameter connectionEF020208

    A number in mm · Do3 in drawing

  6. 33

    Directional vector connectionEF011005

    A coordinate · DV3 in drawing

  7. 34

    Sleeve length (no longer used)EF010520

    A number in mm · P3 in drawing

  8. 35

    Length gusset/threadEF010521

    A number in mm · Q3 in drawing

  9. 36

    Wall thickness connectionEF010546

    A number in mm · s3 in drawing

Port 4

  1. 37

    ConnectionEF000443

    Choose one value

    Insert endDuct end
  2. 38

    Connection purpose according to EN 16798-3EF015774

    Choose one value

    SUP
  3. 39

    Position connectionEF011006

    A coordinate in mm · CA4 in drawing

  4. 40

    Nominal duct diameter connectionEF022923

    A number in mm · DN4 in drawing

  5. 41

    Outer pipe diameter connectionEF020208

    A number in mm · Do4 in drawing

  6. 42

    Directional vector connectionEF011005

    A coordinate · DV4 in drawing

  7. 43

    Sleeve length (no longer used)EF010520

    A number in mm · P4 in drawing

  8. 44

    Length gusset/threadEF010521

    A number in mm · Q4 in drawing

  9. 45

    Wall thickness connectionEF010546

    A number in mm · s4 in drawing

Port 5

  1. 46

    ConnectionEF000443

    Choose one value

    Insert endDuct end
  2. 47

    Connection purpose according to EN 16798-3EF015774

    Choose one value

    ETA
  3. 48

    Position connectionEF011006

    A coordinate in mm · CA5 in drawing

  4. 49

    Nominal duct diameter connectionEF022923

    A number in mm · DN5 in drawing

  5. 50

    Outer pipe diameter connectionEF020208

    A number in mm · Do5 in drawing

  6. 51

    Directional vector connectionEF011005

    A coordinate · DV5 in drawing

  7. 52

    Sleeve length (no longer used)EF010520

    A number in mm · P5 in drawing

  8. 53

    Length gusset/threadEF010521

    A number in mm · Q5 in drawing

  9. 54

    Wall thickness connectionEF010546

    A number in mm · s5 in drawing

Port 6

  1. 55

    ConnectionEF000443

    Choose one value

    Insert endDuct end
  2. 56

    Connection purpose according to EN 16798-3EF015774

    Choose one value

    SUP
  3. 57

    Position connectionEF011006

    A coordinate in mm · CA6 in drawing

  4. 58

    Nominal duct diameter connectionEF022923

    A number in mm · DN6 in drawing

  5. 59

    Outer pipe diameter connectionEF020208

    A number in mm · Do6 in drawing

  6. 60

    Directional vector connectionEF011005

    A coordinate · DV6 in drawing

  7. 61

    Sleeve length (no longer used)EF010520

    A number in mm · P6 in drawing

  8. 62

    Length gusset/threadEF010521

    A number in mm · Q6 in drawing

  9. 63

    Wall thickness connectionEF010546

    A number in mm · s6 in drawing

Port 7

  1. 64

    ConnectionEF000443

    Choose one value

    Insert endDuct end
  2. 65

    Position condensation drainEF015780

    A coordinate in mm · CA7 in drawing

  3. 66

    Outer pipe diameter connectionEF020208

    A number in mm · Do7 in drawing

  4. 67

    Nominal duct diameter connectionEF022923

    A number in mm · DN7 in drawing

  5. 68

    Directional vector connectionEF011005

    A coordinate · DV7 in drawing

  6. 69

    Sleeve length (no longer used)EF010520

    A number in mm · P7 in drawing

  7. 70

    Length gusset/threadEF010521

    A number in mm · Q7 in drawing

  8. 71

    Wall thickness connectionEF010546

    A number in mm · s7 in drawing

Port 8

  1. 72

    ConnectionEF000443

    Choose one value

    Insert endDuct end
  2. 73

    Position air connection to frost protection valveEF016319

    A coordinate in mm · CA8 in drawing

  3. 74

    Outer pipe diameter connectionEF020208

    A number in mm · Do8 in drawing

  4. 75

    Nominal duct diameter connectionEF022923

    A number in mm · DN8 in drawing

  5. 76

    Directional vector connectionEF011005

    A coordinate · DV8 in drawing

  6. 77

    Sleeve length (no longer used)EF010520

    A number in mm · P8 in drawing

  7. 78

    Length gusset/threadEF010521

    A number in mm · Q8 in drawing

  8. 79

    Wall thickness connectionEF010546

    A number in mm · s8 in drawing
